QUICK CAMP
It works in any weather condition day and night thanks to this illuminated, heat-sealed and air-conditioned enclosure.
Our QuickCamp stand is a 20-foot standard ISO cargo container that expands very simply to 24×21 feet. When you expand the Quick Camp, it has a very comfortable work environment, a rest room, an office and even a storage room. Operators work indoors protecting themselves from adverse weather conditions. The tubes are fed from the MegaMc PolyHorse to the remote control QuickCamp. Sealed enclosures, patent pending, keep bad weather out, protect the integrity of the union and keep operators working comfortably.
QUICK CAMP IN ACTION
Click on the photos and videos below to see how the Quick Camp works
SPECIFICATIONS
| Pipe Size Range | Included Machine | Input Power | Electrical Outlets | Part Number |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 High Force | 208V, 60Hz, 3Ph | 120V, 60Hz | A3658701 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 Medium Force | 208V, 60Hz, 3Ph | 120V, 60Hz | A3658702 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 Low Force | 208V, 60Hz, 3Ph | 120V, 60Hz | A3658703 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 High Force | 240V, 50Hz, 3Ph | 240V, 50Hz | A3658704 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 Medium Force | 240V, 50Hz, 3Ph | 240V, 50Hz | A3658705 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 Low Force | 240V, 50Hz, 3Ph | 240V, 50Hz | A3658706 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 High Force | 415V, 50Hz, 3Ph | 240V, 50Hz | A3658707 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 Medium Force | 415V, 50Hz, 3Ph | 240V, 50Hz | A3658708 |
| 8″ IPS – 24″ OD (225mm – 630mm) | 630 Low Force | 415V, 50Hz, 3Ph | 240V, 50Hz | A3658709 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 High Force | 208V, 60Hz, 3Ph | 120V, 60Hz | A3658501 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 Medium Force | 208V, 60Hz, 3Ph | 120V, 60Hz | A3658502 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 Low Force | 208V, 60Hz, 3Ph | 120V, 60Hz | A3658503 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 High Force | 240V, 50Hz, 3Ph | 240V, 50Hz | A3658504 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 Medium Force | 240V, 50Hz, 3Ph | 240V, 50Hz | A3658505 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 Low Force | 240V, 50Hz, 3Ph | 240V, 50Hz | A3658506 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 High Force | 415V, 50Hz, 3Ph | 240V, 50Hz | A3658507 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 Medium Force | 415V, 50Hz, 3Ph | 240V, 50Hz | A3658508 |
| 12″ IPS – 36″ OD (340mm – 900mm) | 900 Low Force | 415V, 50Hz, 3Ph | 240V, 50Hz | A3658509 |
| QuickCamp™ | |||
| Length | 260″ (6,600 mm) | ||
| Length (from QuickCamp Shelter to MegaMc PolyHorse) | 537″ (13,640 mmm) | ||
| Width | 295″ (7,490 mm) | ||
WIN TO WEATHER CLIMATE ADVERSITIES
The QuickCamp shed is a closed, illuminated, heat insulated and heated enclosure that allows operators to fuse tubes in all weather conditions both day and night. This set includes the house itself, a 630 or 900 fusion car that is already installed inside the house, the MegaMc PolyHorse and the MegaMc rollers for maximum productivity.
Our QuickCamp stand is a 20-foot standard ISO cargo container that expands very simply to 24×21 feet. When you expand the Quick Camp, it has a very comfortable work environment, a rest room, an office and even a storage room. Operators work indoors protecting themselves from adverse weather conditions. The tubes are fed from the MegaMc PolyHorse to the remote control QuickCamp. Sealed enclosures, patent pending, keep bad weather out, protect the integrity of the union and keep operators working comfortably.
INSTALL THE QUICKCAMP
EASILY AND QUICKLY
WITH YOUR DISPLAY SYSTEM YOU WILL BE ABLE TO PUT HANDS TO THE WORK QUICKLY
We ship the house as a standard 20 foot ISO container. You will only need two operators to open and start it, mount the walls, floor and ceiling. In an instant you will have your booth mounted. This set includes a 630 or 900 fusion car, which is installed inside the QuickCamp. The leveling jacks help maintain the correct position of the unit. In addition, air conditioning units can be installed quickly in the windows.
WEATHER
TIGHT SEAL
KEEPS THE ELEMENTS OUT
The QuickCamp provides continuous pipe fusion in conditions that may otherwise shut down a jobsite. It’s made for 24/7 operations so your crew can keep working. The QuickCamp’s unique pipe seals keep the elements out to maintain fusion joint integrity and make a more comfortable working environment inside the shelter. The pipe is fed via remote control from the MegaMc® PolyHorse® through the pipe seals into the QuickCamp and require little operator interaction.
COMFORTABLEENVIRONMEN
KEEP WORKING NO MATTER THE CONDITIONS OUTSIDE
The QuickCamp is well lit, both inside and out. Its 2.5″ thick, R15-rated insulated walls help to regulate the inside temperature while two heating and air units allow operators to create a comfortable work environment. Multiple electrical outlets can be found inside for powering any personal equipment. And there is plenty of room inside for office space, a break room or storage.
ONLY ONE
OPERATOR REQUIRED
PRODUCTIVITY-ENHANCING ACCESSORIES SAVE TIME & MONEY
While the QuickCamp works to keep the elements out — saving downtime on the jobsite — it also provides the tools to allow operators to work more efficiently. Thanks to the included MegaMc® PolyHorse®, technicians can work an entire shift independently. The hydraulically-powered racks hold a day’s worth of pipe and allow one operator to load, align and fuse pipe via remote control from inside the QuickCamp shelter — eliminating the wait for heavy equipment to load pipe for each fusion joint.
LEADERS OF THE PLASTIC
PIPE WELDING INDUSTRY
MAXIMUM PERFORMANCE ALWAYS GUARANTEED
All Plastic Pipe Welding machines and equipment are specifically designed to withstand the most adverse conditions and climates. We guarantee that our machines will last for years. But if that were not enough for you, all our machines come with the maximum warranty period possible in the field of plastic welding, 5 years warranty.
ADITIONAL FEATURES
| QuickCamp 630 | QuickCamp 900 | |
| Shelter folds into standard ISO, 20′ cargo container for shipping | ✓ | ✓ |
| Folded shelter contains fusion machine carriage | ✓ | ✓ |
| Carriage slides out of shelter for in-ditch use or fusing stub ends and fittings | ✓ | ✓ |
| Ample space for an office, breakroom or storage of extra gear | ✓ | ✓ |
| Electrical outlets to power personal equipment | ✓ | ✓ |
| Hydraulic Power Unit powers fusion carriage with customer-furnished generator | ✓ | ✓ |
| One-size-fits-all pipe seals | ✓ | ✓ |
| Included heating and air-conditioning units fit into fold-out shelves | ✓ | ✓ |
